Description
一、the use of the environment
In the following circumstances, the generator can be rated for operation
(1)The altitude does not exceed 1000 meters.
(2)The cooling air temperature (-15 to 40 DEG C)
(3)The relative humidity of not more than 90%
二、product features
(1)A reliable automatic voltage regulating exciter system and, optionally, a permanent magnet generator system and can provide a constant excitation in a variety of situations.
(2)It is easy with the grid or other generators in parallel.
(3)The balancing of the rotor, with sealed ball bearings, bearings with single and double bearing two structure.
(4)The simple installation, convenient maintenance: with easy access to terminals, rotating rectifier and coupling bolts.
(5)The multi specifications adaptor and single bearing coupling disc.
(6)It meets all the dominant land use standard.
- Parameter
Model(mode)
RevisedRated power(kva)400v
1500rpm/50HZRated power(kw)400v
1500rpm/50HZRated power(kva)440v
1800rpm/60HZRated power(kw)440v
1800rpm/60HZMP-4-404D 800 640 960 768 MP-4-404E 910 728 1073.8 859.0 MP-4-404F 1000 800 1180 944 MP-4-404G 1125 900 1327.5 1062 MP-4-404H 1250 100 1475 1180 MP-4-404J 1400 1120 1652 1321.6
