Description
DEUTZ is established in 1864 which is one of the world class diesel engine manufacturers and had been produced the first internal combustion engine in the world. Its headquarter is located at Cologne in Germany. Production bases are located at Cologne, Worms, Mannheim and so on. Our company uses the diesel engine production technologies in the nineties which are imported by Huabei diesel engine factory, Weichai diesel engine factory and Shijiazhuang construction machinery plant. It has a great advantage in generator which powers are ranged from 10 to 1230KW. Reliable performance, excellent in quality, compact size, low fuel consumption.
- Parameter
Model Prime power Engine model No.of cyls Bore/stroke Fuel Cons. Dimension Weight(kg) KW KVA (mm) (L/hr) (L*W*H) (mm) Air-cooled Series GF2-12D 12 15 F2L912 2 100/120 4 1400*800*1100 500 GF2-20D 20 25 F3L912 3 100/120 4 1700*800*1100 700 GF2-24D 24 30 F4L912 4 100/120 9.7 1900*800*1150 800 GF2-36D 36 45 F4L912T 4 102/125 9.7 2000*800*1150 950 GF2-40D 40 50 F6L912 6 100/120 14.5 2250*800*1150 1150 GF2-48D 48 60 F6L912T 6 100/120 14.5 2250*800*1150 1200 GF2-64D 64 80 BF6L913 6 102/125 24.9 2400*800*1250 1300 GF2-76D 76 95 BF6L913C 6 102/125 30.7 2500*800*1350 1500 Water-cooled Series GF2-20D 20 25 D226B-3D 3 105/120 6.5 1620*780*1200 780 GF2-24D 24 30 D226B-3D 3 105/120 6.5 1620*780*1200 780 GF2-34D 34 42 TD226B-3D 3 105/120 9.6 1620*780*1200 810 GF2-48D 48 60 TD226B-4D 4 105/120 13.6 1950*750*1650 950 GF2-80D 80 100 TD226B-6D 6 105/120 20.8 2230*840*1700 1210 GF2-104D 104 130 TBD226B-6D 6 105/120 26.4 2300*840*1740 1350 GF2-120D 120 150 TBD226B-6D5 6 105/120 30.3 2300*840*1740 1450 GF2-68D 68 85 BF4M1013E 4 108/130 11.9 1920*740*1520 1150 GF2-80D 80 100 BF4M1013EC 4 108/130 14 2056*870*1472 1200 GF2-104D 104 130 BF6M1013E 6 108/130 17.5 2473*900*1546 1330 GF2-121D 121 151 BF6M1013EC 6 108/130 20.3 2473*900*1546 1330 GF2-150D 150 188 BF6M1013FC 6 108/130 28 2595*900*1546 1540 GF2-165D 165 206 BF6M1013FC 6 108/130 28 2595*900*1546 1540 GF2-190D 190 237.5 BF6M1015 6 132/145 32.2 2453*1040*1822 1880 GF2-260D 260 325 BF6M1015C 6 132/145 44.1 3060*1315*2035 2300 GF2-280D 280 350 BF6M1015C2 6 132/145 47.6 3060*1515*2035 2490 GF2-300D 300 375 BF6M1015CP 6 132/145 50.4 3060*1515*1095 2540 GF2-345D 345 431 BF8M1015C 8 132/145 60.4 3208*1515*1975 2870 GF2-380D 380 475 BF8M1015C2 8 132/145 66.5 3208*1515*1975 2970 GF2-400D 400 500 BF8M1015CP 8 132/145 70.7 3200*1815*1978 3190
